Hospital lift

Price 700000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Hospital lift Specification

Pit Depth
1600 mm

Noise Level
60 dB

Voltage
380V

Car Dimension
1100 mm x 2100 mm

Overhead Height
4200 mm

Load Capacity
Up to 6 Persons or Medical Stretcher

Usage
Hospital, Medical Facilities

Door Opening Size
900 mm x 2000 mm

Inclination
0 (Vertical)

Machine Room Size
2000 mm x 2500 mm

Type
Other

Hoist Way Size
1800 mm x 2300 mm

Material
Stainless Steel (304/316 grade)

Drive Type
Gearless

Power Supply
3 Phase, 50/60 Hz

Speed
1.0 m/s

Max. Lifting Height
Up to 40 meters

Max. Lifting Weight
450 Kg

Mechanism Type
Traction

Working Temperature
-10C to +40C

Control Device
Microprocessor Based Control Panel

Safety Device
Overload Sensor, Emergency Stop, Interlock Switches

Capacity
450 Kg

Operation
Vandal Resistant, Micro-touch Button Panel

Finish
Hairline Stainless Steel finish

Handrail
Stainless Steel, One Side

Guide Rail
Smoothened, precision T-rail

Lubrication
Automatic Lubricating System

Ceiling
Decorative Stainless Steel False Ceiling

Compliance
EN81, IS Standards

Floor Display
Digital, LED/LCD

Lighting
LED automatic cabin lighting

Communication
Two-way Intercom

Backup System
Automatic Rescue Device (ARD) for power failure

Fire Protection
Fire-rated doors, Emergency alarm

Door Type
Automatic Center Opening

Suspension Rope
Steel Wire Rope

Leveling Accuracy
5 mm

Hospital lift Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Hospital lift

Experience the finest in hospital transport with our 450 Kg Stainless Steel Hospital Elevator, delivering first-class safety and value. Engineered for medical excellence, it features a gearless drive, precision microprocessor control, and automatic center opening doors for optimal access. Cost-effective and robust, it includes LED/LCD digital displays, vandal-resistant micro-touch panels, and an automatic rescue device for power failures. The stainless steel handrail, fire-rated doors, and two-way intercom offer a glorious blend of safety and comfort. Compliant with EN81 and IS Standards, it's ideal for modern medical facilities seeking reliable, high-performance elevation solutions.

Optimized Medical Transport: Usage & Competitive Edge

Designed exclusively for hospitals and medical centers, the 450 Kg Stainless Steel Hospital Elevator is used for swift patient transfer, including stretchers. Its competitive advantages include first-class EN81 & IS compliance, a micro-touch button panel, and a smooth, silent gearless mechanism. This elevator offers reliable access across up to 40 meters, providing value for facilities requiring frequent, secure vertical mobility and patient comfort.

Packaging, Delivery & Handover Details

Each elevator is meticulously packed for domestic markets, ensuring secure transit and minimal outlay on installation. Packaging includes protective wrapping and reinforced crates for every component. Delivery time typically ranges from 6-8 weeks post-order confirmation, with on-site handover and detailed installation support. While sample units are not available due to customization, detailed specification sheets are provided upon request.

FAQ's of 450 Kg Stainless Steel Hospital Elevator:

Q: How does the elevator ensure passenger safety during power failures?

A: The elevator is equipped with an Automatic Rescue Device (ARD), which activates during power failures to safely transport passengers to the nearest floor and open the doors automatically.

Q: What types of facilities can benefit from installing this hospital elevator?

A: Hospitals, clinics, and other medical centers seeking efficient, high-capacity patient transport-especially those needing stretcher accommodation-will benefit from this elevator's reliable and cost-effective operation.

Q: Where does the elevator comply with the required safety and quality standards?

A: This model meets EN81 and IS standards, ensuring compliance with international and domestic elevator safety and performance regulations.

Q: What are the advantages of using microprocessor-based control panels in this elevator?

A: Microprocessor-based control panels provide precise leveling accuracy (within 5 mm), enhance operational reliability, and enable advanced diagnostic and safety features.

Q: What is the typical delivery time and what does the packaging process include?

A: Delivery is typically handled within 6-8 weeks after order confirmation, with each unit securely packaged for domestic dispatch, ensuring safe arrival and smooth installation.
